Nexcom NISE 505 Fanless Computer

Main Features:

  • Onboard Intel® Celeron® processor J1900 quad core, 2.42GHz
  • 1 x HDMI display
  • 3 x Intel® I210-IT GbE LAN ports; support WoL, teaming and PXE
  • 2 x USB 2.0
  • 1 x mini-PCIe socket for optional Wi-Fi/BT modules
  • 1 x mini-PCIe socket for optional mSATA storage
  • 1 x RJ45 COM serial port for RS232 signal
  • Support -5~55 degree C operating temperature
  • Support 12V DC input


SKU: Nexcom NISE 505 Categories: ,


Nexcom NISE 505 Fanless Computer

Powered by the latest generation of Intel® Celeron® processor J1900 (formerly codenamed “Bay Trail”), NISE 505 series positions at the intelligent IoT gateway for factory automation and for smart city applications. Up to 4G DDR3L memory, the NISE 505 series support operating temperature from -5 up to 55 degree C with 12V DC input with +/-20% range. The NISE 505 series have strong connectivity – Ethernet-based LAN port and traditional RS232, mainly for Modbus TCP or Modbus RTU communication. For wireless connectivity, there is 1 x mini-PCIe sockets which can support optional wireless modules for IoT applications, for example, Wi-Fi, Bluetooth module. NISE 505 is definitely the best choice for M2M intelligent system as an intelligent IoT gateway.

We also offer a range of Nexcom Industrial Panel PCs, low cost Panel PCs and Panel Mount Monitors.
