Nexcom NISE 53-E01/E02 Fanless Embedded Computer

Main Features:

  • Onboard Intel® Celeron® processor J6413, 1.8 GHz, or Atom® processor x6211E, 1.3Ghz
  • 3 x HDMI (triple displays)
  • 2 x USB 3.0, 2 x USB 2.0
  • 1 x RS232/485, 1 x RS232/485 with auto flow control
  • 3 x GbE LAN ports
  • 1 x Full-size mini-PCIe
  • 1 x Front accessible M.2 Key B
  • 1 x Internal M.2 Key B
  • Support operating temperature from -10°C to 60°C
  • Support +12V/24V DC input; support ATX power mode


SKU: Nexcom NISE 53-E01/E02 Category:


Nexcom NISE 53-E01/E02 Fanless Embedded Computer

NISE 53 is a fanless PC powered by the newest generation Intel® Celeron® J series and Atom® x6000 series (formerly code-named “Elkhart Lake”) processors. It offers power-efficient performance designed for the next generation of industrial edge-connected embedded systems that require highresolution graphics and low power consumption – such as industrial automation, intelligent transportation, retail, and smart city IoT solutions. NISE 53 can operate in an extended temperature range from -10°C to 60 °C, indicating its reliability in industrial environments. NISE 53 supports up to 3 display outputs simultaneously and delivers superior graphics capabilities via Intel® UHD graphics 16EUs. NISE 53 has strong connectivity – 3 x Gbe LAN ports, and 2 x COM ports, mainly for Modbus TCP or Modbus RTU communication. NISE 53 supports efficient scalable networks and storage configurations with an internal 1 x M.2 slot for 4G LTE, 1 x full-size mini-PCIe slot for Wi-Fi and Bluetooth, and front-accessible 1 x M.2 slot for storage. NISE 53 drives performance, integration, and versatility for industrial environments, offers a lower total cost of ownership, and supports 12 VDC/24 VDC and onboard TPM2.0 for enhanced security.
