Nexcom NISE 3800E2/P2/P2E Fanless Embedded PC

Main Features:

  • Support 6th generation Intel® Core™ i7/i5/i3 LGA socket type embedded processor
  • Intel® Q170 PCH
  • Support 1 x 2.5″ SATA HDD
  • 1 x DVI-D, 1 x DP, and 1 x HDMI with independent display support
  • Three Intel® GbE LAN ports; support WoL, teaming and PXE
  • 1 x External M.2 (M-key 2242) socket and 1 x SIM card socket
  • 4 x USB 3.0, 2 x USB 2.0, 2 x RS232/422/485 with auto flow control
  • 2 x Internal mini-PCIe socket support optional Wi-Fi/3.5G/mSATA/Fieldbus
  • Support +9V to 30VDC input; ATX power mode
  • 2 x PCI or PCIe x4 expansions

Downloads

SKU: Nexcom NISE 3800E2/P2/P2E Category:

Description

Nexcom NISE 3800E2/P2/P2E Fanless Embedded PC – 6th Generation Intel® Core™ i7/i5/i3 LGA Fanless System with Expansion

Featuring high compute power and outstanding graphics capabilities, fanless Core™-i Performance Series models support a variety of external displays. Every Core™-i Performance product offers a superb complement to digital signage, industrial automation, smart machinery, and transportation.

Nexcom NISE 3800E2/P2/P2E is integrated with 6th generation Intel® Core™ i7/i5/i3 processors, Nexcom NISE 3800 series is the fanless PC designed for industrial applications which demand high CPU and graphics performance. NISE 3800 supports up to 32G DDR4 memory and have several options on storage devices like M.2, HDD, mSATA or SSD. NISE 3800 supports wide range of DC input from +9V to 30V DC input, and can be operated in an extended operating temperature range between -5 to 55 Celsius degree. For extended module availability, NISE 3800 also designed two internal mini-PCIe sockets to support IoT applications (integrate with optional GbE LAN, Wi-Fi, 3.5G module) and common communication applications (integrate with optional GPIO, RS232/422/485 module).

Core™-i Performance

Featuring high computing power and outstanding graphics capabilities, fanless Core™-i Performance Series models support a variety of external displays. Every Core™-i Performance product offers a superb complement to digital signage, industrial automation, smart machinery, and transportation.

We also offer a range of Nexcom Industrial Panel PCs, low cost Panel PCs and Panel Mount Monitors.



Additional information

Manufacturer

Nexcom
