10.4” Axiomtek GOT710S Railway Touchscreen Panel PC

Main Features:

  • Sunlight readable 10.4″ SVGA TFT LCD with 1000 nits of high brightness
  • Intel Atom® processor E3845 1.91 GHz
  • M12-type lockable connectors design
  • Alternative keypad control in the front bezel
  • Auto-dimming for different environments
  • -40°C to +70°C wide temperature range
  • Typical 24 to 110 VDC wide power input range, EN 50155
  • Class S3 20ms power interruption protection
  • EN 50155, EN 45545-2 certified for railway application



Downloads

SKU: Axiomtek GOT710S Category:

Description

10.4” Axiomtek GOT710S Railway Touchscreen Panel PC

Axiomtek GOT710S EN50155 S3 10.4″ SVGA TFT LCD Railway Fanless Touchscreen Panel PC with Intel Atom® Processor E3845 1.91 GHz (-40°C to +70°C)

The GOT710S is an EN 50155 and EN 45545-2 certified 10.4-inch fanless touch panel PCs for train control and rail signaling. Featuring sunlight-readable technology and auto-dimming function, the GOT710S is readable even under intense sunlight and in dark environments. It has an IP65-rated aluminum front bezel for dust-proof plus water-resistant; furthermore, it has a full range DC power input from 24 to 110 VDC and an extended operating temperature range from -40°C to +70°C. For safety concerns, this railway fanless panel PC also can endure a 20ms power interruption (EN 50155 Class S3) from an unexpected power outage. The GOT710S is specifically designed to serve the complex needs of the railway industry and operate reliably under extreme conditions such as major temperature fluctuations and vibration.
